৳ 0
Call For Price
| Basic Information | ||
| Supported CPU | AMD Ryzen™ processor AMD 7th Generation A-series/ Athlon™ processor |
|
| Chipset | AMD A320 | |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 24.4cm x 19.5cm | |
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, running at x16 (PCIEX16) * Actual support may vary by CPU. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 2.0 standard.) |
|
| Graphics Slot | D-Sub DVI-D HDMI |
|
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2* SSD support) * Actual support may vary by CPU. * Supports only M.2 SATA SSDs when using an AMD Athlon™ 200-series/ 7th Generation A-series or Athlon™ APU. |
|
| Memory | ||
| Type | Dual channel memory architecture | |
| Slots | 2 x DDR4 DIMM | |
| Supported Memory | Support for DDR4 3200(O.C.)/2933(O.C.)/2667*/2400/2133 MHz memory modules * Actual support may vary by CPU. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | 32 GB | |
| Graphics | ||
| Integrated Graphics | Integrated Graphics Processor | |
| Supported Graphics | 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096×2160@24 Hz * Support for HDMI 1.4 version. |
|
| Max Shared Memory | 2 GB | |
Connector & Ports |
||
| HDMI | 1 x HDMI port | |
| USB (s) | Chipset: 2 x USB 3.1 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) CPU: 4 x USB 3.1 Gen 1 ports on the back panel |
|
| LAN Port (s) | Realtek® GbE LAN chip (10/100/1000 Mbit) | |
| Supported Storage | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2* SSD support) * Actual support may vary by CPU. * Supports only M.2 SATA SSDs when using an AMD Athlon™ 200-series/ 7th Generation A-series or Athlon™ APU. 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10 * Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 connector. |
|
| Audio | Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out |
|
| Internal I/O Ports | 24-pin ATX main power connector 8-pin ATX 12V power connector CPU fan header system fan header M.2 Socket 3 connector SATA 6Gb/s connectors front panel header front panel audio header S/PDIF Out header USB 3.1 Gen 1 header USB 2.0/1.1 headers Trusted Platform Module (TPM) header (2×10 pin, for the GC-TPM2.0 module only) speaker header Clear CMOS jumper chassis intrusion header |
|
| Warranty Information | ||
| Manufacturing Warranty | 03 years | |
| Brand | |
|---|---|
| Processor Brand |
AMD |
| Generation |
7th Gen |
| RAM Type |
DDR4 |
| Bus Speed |
2133 MHz ,2400 MHz ,2666 MHz ,3200 MHz |
| RAM Slot |
2 |
| M.2/NVMe Expention slot |
1 |
| HDMI Port |
YES |
The latest price of Gigabyte GA-A320M-S2H AMD Micro ATX Motherboard in Bangladesh is .00৳. You can buy the Gigabyte GA-A320M-S2H AMD Micro ATX Motherboard at best price from our website or visit any of our showrooms.
